Challenger 3
Increase Your Harvest
Challenger 3
3 Rows Forage Harvester
540 RPM
PTO WORKING CYCLE
210CM
WORK WIDTH
110 HP
MINIMUM POWER REQUIREMENT
Take a Close Look
Explore the Challenger 3 from every angle with 360-degree animation.
Low Power Requirement
Maximum Security
540-750-1000
RPM Options
In front of you is the first and only three-row silage machine in the sector that can operate with 110 hp. Çelikel® proves once again with its engineering talent that large machines can also operate efficiently with low power requirements.
In the Challenger 3®, the machine safety is ensured against undesirable situations with the power transmission system combined with belts and gear boxes .
Row-independent silage machine that adapts to different tractors; offers options to be connected to the front, back and side of the tractor; offers full efficiency use with 540, 750 and 1000 rpm transmission options.
Front Drum
The drum cuts the crops with its powerful knives, brings them to suitable sizes for the silage process and then transfers these cut pieces to the receiving unit or the next stage of the machine. This system increases the efficiency of the cutting process and ensures that the crops are cut correctly.
SuperBlow
There are specially designed throwing paddles in the machine flywheel system. These paddles perform the sweeping process in the shredding chamber very well and quickly direct all the silage in the machine to the chimney. With the help of the Challenger®'s powerful blowing system, hydraulically controlled chimney and steerable hat, the silage can be loaded to the desired area of the trailer.
360° Rotating Funnel
The chimney rotation direction, which is limited to 90° in its counterparts, has been increased to 360° in Challenger® thanks to the new clamp system.
%20copy.png)
2 Different Working Directions
Challenger 3® offers its users different harvesting alternatives. This multi-purpose machine has the ability to harvest in two different ways: in front of the tractor and behind the tractor.
Patented Flywheel
12 specially designed flywheel blades are made of high quality materials resistant to wear. This prevents the cost of frequent blade replacement.
Technical Specifications
You can review the technical specifications of Challenger 3 in the table below.
Özellikler | Challenger 3 |
|---|---|
WORKING WIDTH | 210 cm |
WIDTH (TRANSPORT CONDITION) | 2420 mm |
WIDTH (WORKING POSITION) | 4115 mm |
HEIGHT (TRANSPORT POSITION) | 2475 mm |
HEIGHT (WORKING POSITION) | 4165 mmm |
LENGTH (WORKING POSITION) | 2600 mm |
THREE-POINT HITCH SYSTEM | CATEGORY II - III |
NUMBER OF CIRCULAR BLADES | 6 |
NUMBER OF WHEELS | 2 |
WEIGHT | 1520 kg |
TIRE SIZE | 165x70x13 |
SHREDDING SIZE | ADJUSTABLE (3-10 mm) |
NUMBER OF FIXED BLADES | 1 |
NUMBER OF SHREDDER BLADES | 12 |
NUMBER OF SHREDDER BLADES | 12 |
NUMBER OF THROWING BLADES | 12 |
WORKING POSITION | FRONT / REAR |
PTO OPERATING SPEED | 540 / 1000 RPM |
MINIMUM POWER REQUIREMENT | 80 kW (110 hp) |
GRAIN CRUSHING AND SHREDDING SYSTEM | - SPECIAL DESIGN SHREDDER
BLADE TOP SURFACE
- SHREDDER BLADES
- CHAMBER INSIDE GGG60 CASTING CRUSHER
(Optional) |
SAFETY SYSTEM | POWER TRANSMISSION BELT |
MACHINE DRIVE TRANSMISSION | GEARBOX AND FLEXIBLE TRANSMISSION COMBINATION |
Video
You can view the videos of Challenger 3.
Photograph
Photos of the Challenger 3 You can review.
